Remote Packet Capture with Wireshark

This guide shows how to set up Wireshark to remotely capture traffic via SSH using tcpdump.

Prerequisites

• Wireshark installed on your local machine
• SSH access to the remote host
• tcpdump installed on the remote host

Setup Remote Host

Wireshark runs tcpdump non-interactively over SSH, so sudo will fail if it requires a password prompt. Grant tcpdump the capture capability directly on the remote host instead:

sudo setcap cap_net_raw+ep $(which tcpdump)

Setup Wireshark

1. Go to: Capture → Options → Manage Interfaces
2. Click the gear icon next to SSH Remote Capture
3. Set the interface details:
   • Remote SSH Server Address: IP address of the remote host
   • Remote SSH Server Port: 22
4. In the Authentication tab, fill in:
   • Remote SSH Server Username
   • Remote SSH Server Password or Path to SSH Private Key (e.g. ~/.ssh/id_rsa)
5. In the Capture tab, configure what to capture:
   • Remote Interface: the network interface on the remote host (e.g. eth0)
   • Remote Capture Filter: a BPF filter to limit captured traffic (e.g. not port 22)
6. Save and Start the capture.
